Carthago C1 Tourer T 145 RB LE Lightweight Specification
The Carthago c-tourer T 145 RB LE Lightweight combines comfort and practicality in a streamlined design. This brand new 2026 model offers space and efficiency for touring.
Motorhome Technical Data:
- Mercedes-Benz Sprinter
- 9G-TRONIC automatic transmission
- AL-KO low frame special light 315 CDI
- Diesel 2.0l (150 HP / 110 kW)
- 3,900mm wheelbase
- 1,980mm headroom in living area
- 1,200mm rear garage height
- Technically permissible gross vehicle weight: 3,500kg
- Rear bed dimensions: 1,900 / 2,000x850mm
- 133l fridge with 12l freezer
- Truma Combi 6 heating
- 150l fresh water
- 140 waste water
- Battery capacity: 80 Ah UPGRADED TO 90 AH LITHIUM-ION BATTERY INC. BATTERY COMPUTER
- Sockets: 4x 230V / 1x USB
Carthago C1 Tourer T 145 RB-LE Lightweight Equipment Includes:
- Chassis
- Carthago special light AL-KO low frame
- All-weather tyres (M+S)
- 16-inch steel wheels
- Daytime running lights integrated in headlights
- Mud flaps on rear axle
- Fix & Go breakdown kit
- Engine: 2.0 l diesel with Adblue (22 l), 150 HP / 110 kW, 4 cylinders, 330 Nm, Euro VI E, front-wheel drive
- 9G-Tronic automatic transmission incl. hillholder
- Start / Stop system
- Keyless Start incl. Start/Stop button
- Driver / passenger airbag
- Side Wind Assist, hillholder, ABS, ASR, EBV, ESP
- Driver and passenger cup holders, glove compartment on passenger side (LHD)
- Hinged lid for storage compartment
- Automatic driving light control
- Mercedes-Benz emergency call system, breakdown management
- Fleece battery 12 V / 92 Ah
- 65-litre fuel tank (Mercedes-Benz)
- Active Brake Assist and Driver Drowsiness Detection
- Original Mercedes-Benz wheel trims
- Pre-wiring (cable set) for habitation door central locking system
- Electric hot air auxiliary heating in cab
- Liner Premium-Class Body Construction
- 10-year water ingress guarantee
- Wood-free bodywork with GRP roof and floor covering
- Roof/wall connection via curved roof and frame member
- Roof system rails at side with rainwater drainage
- Side and rear walls with aluminium on the interior and exterior
- RTM hard foam insulating core in roof, floor and side wall
- Floor to side wall connection using aluminium frame member bonded over its entire surface with additional cold stop
- Total wall and roof thickness, 38 mm
- Exterior hatches made from original ‘Carthago Isoplus’ side wall material
- Internal/external flap seal, outer seal as water spray protection
- Exterior hatches and main cabin door with internal hinges
- Segmented side skirts made from aluminium profile
- Dynamic design rear (not 148 KB-LE H) in Mercedes-Benz models incl. design enhancements
- Carthago rear lights with Carthago ‘C’ branding in LEDs
- Seitz S4 main cabin window, double frame with insulated glazing and no thermal bridge, insect screen roller blind and pleated blackout blind
- LED exterior light above main cabin door with rain deflector
- Electrically extending entrance step for habitation door with warning buzzer
- Cab
- Body-coloured bumper and side attachments
- Radiator grille with chrome elements (Mercedes-Benz)
- T-pod in GRP
- Cab doors with central locking and electric windows on driver’s and passenger sides (LHD)
- Aguti driver’s and passenger’s comfort seats in living area material, rotatable, padded armrests (Mercedes-Benz)
- Electrically adjustable and heated exterior rear view mirrors
- All-around overhead storage cabinets above cab
- Partition curtain to living area
- Double Floor Storage Compartment
- Usable height up to 55.5 cm
- Through-loading storage compartment with lighting and heating
- Outside access via several large hatches
- Interior access via the L-shaped lounge seating area with patented fitting, fold-up side seat bench and via the large living area floor hatches in the entrance and kitchen area
- Central through-loading storage compartment (interior height 22 cm) with extra-low double floor storage compartment (usable height 46 cm)
- Large Scooter Garage
- Scooter garage load capacity up to 350 kg
- Large garage door on passenger side, additional door on driver’s side (LHD)
- Garage floor with GRP on top and bottom, anti-slip coating
- With all-around frost-proof insulation and heating
- Lashing system via aluminium frame member, including eight lashing eyes
- Interior
- “Casablanca 2” style range: Fine Cherry furniture finish with large overhead cabinet fronts in bicolour appearance in high-gloss ivory combined with modern accents in anthracite black
- Living Area
- Inside of walls and roof with microfibre, climate-regulating wall covering
- L-shaped lounge seating area with side bench seat
- 360° living area table, rotatable using a foot pedal and movable in two directions
- Swivel-out shoe cabinet with storage system in bench seat base, including LED accent light
- Seat upholstery with multilayer premium foam core and back support function
- “Durafix” double connecting technology: furniture parts screwed together and mortised
- Hatch closer with soft closing mechanism
- Curtain system including removable decorative curtain
- Kitchen
- Kitchen countertop as visual room divider and additional worktop
- Kitchen work surface in scratch-resistant slate-effect
- Worktop lit from underneath with LED light strip
- Kitchen unit with cutlery drawer
- “Easy glide” kitchen drawers with roller-mounted and soft-close mechanism
- Separate waste bins in separate hygiene area
- 3-ring hob with divided glass cover (one-piece in 143 KB-LE models) with robust enamelled wire pan support and stainless steel base
- Round stainless steel sink embedded in work surface with multifunctional sink cover including wall holder for extending size of worktop
- Mixer tap in metal design at practical pot height
- Kitchen rear wall in cream decorative glass
- Large refrigerator with door opening on both sides (143 KB-LE, 145 RB-LE, 147 RB-LE K, 148 RB-QB K models: slim tower) with separate freezer compartment, automatic energy source selection 12 V / 230 V / gas mode
- Mini Heki skylight
- Bathroom and Dressing Room
- Dressing room with lockable washroom door or luxury bathroom door to living area
- Luxury bathroom with separate shower room
- “One level” step-free shower access
- Towel rail above round shower
- Shower floor inlay in living area floor design, removable for showering
- Hand-held shower head height-adjustable on chrome rail
- Roof light in shower room
- Mini Heki skylight in washroom
- Washbasin base cabinet with toilet roll holder, countertop washbasin and mirror
- Sleeping
- Fixed beds in rear area
- Two-part heated and ventilated slatted frame
- 7-zone, high-quality cold foam mattress
- Mini Heki skylight
- Lengthways single beds: Raisable head section
- Fixed access steps
- Wardrobes beneath the beds, lowered into the double floor, with lift function and divided mattress
- All-around overhead storage cabinets
- On-Board Technology
- Water
- Fresh water and waste water tank in heated double floor, cleaning opening via living area floor hatch or scooter garage (depending on model)
- Central water drain in central double floor
- Low-maintenance pressurised water pump system
- Gas
- External gas bottle compartment in low position, exterior hatch with separate prop strut (depending on model)
- Holds 2 x 11 kg gas bottles
- Main gas taps in kitchen area
- Electrical System
- Electrical centre in scooter garage including charger, fuses, fuse protection, 16 A automatic charger with automatic cut-off in the event of low voltage
- Heated battery centre, with 1 x 80 Ah gel battery in double floor, access via double floor storage compartment on driver’s side (LHD), main power switch UPGRADED TO 90 AH LITHIUM-ION BATTERY INC. BATTERY COMPUTER
- Truma CP+ digital control panel for hot air heating, behind technical panel above habitation door
- 230 V socket in entrance area, kitchen, bathroom, scooter garage
- USB socket in cab
- Innovative Light Concept
- Ceiling canopy with additional LED spotlights and indirect LED lighting
- LED accent light in kitchen area
- Work light and ambient lighting can be switched on separately
- Heating Technology
- Hot air vents in living area, double floor, scooter garage and habitation door entrance
- Underfloor heating effect due to heated double floor with heat storage
Options Fitted to this Carthago C1 Tourer T 145 RB-LE Lightweight for the UK Include:
- Basic Plus Package consisting of:
- Wheel trims
- Tempmatic semi-automatic air conditioning system
- Cruise control
- Charge booster
- Front axle with increased load bearing capacity
- Leather steering wheel with multifunctional buttons option
- Instrument cluster with colour display
- Rain sensor
- Electric handbrake
- Heat-insulating glass with band filter on windscreen
- Cab blind system: pleated blind on windscreen and side windows
- Cab comfort seats with tilt and height adjustment (front/rear)
- Pre-wiring for radio with roof aerial with DAB+, speakers (4x)
- MBUX 10.2″ multimedia system inc. sat nav and DAB+
- Traffic sign assist
- Midi Heki skylight with LED spotlights above the L-shaped lounge seating area
- Large scooter garage door on driver’s side (LHD)
- XL habitation door “premium two 2.0” (width 63cm) with double locking, window and insect screen blind
- 90 Ah lithium-ion battery inc. battery computer instead of 80 Ah gel battery
- SOG toilet ventilation
- USB socket in overhead storage cabinet above rear bed
- Heating | Air Conditioning
- Truma Combi 6E (additional electric heating element 2 x 900 Watt / 230 V)
- Multimedia
- 32″ TV wall bracket in the entrance area, rotatable by 180°
Extra Items Available for the Carthago C1 Tourer T 145 RB-LE Lightweight Motorhome
Order your Carthago C1 Tourer T 145 RB-LE Lightweight to your own specification. Choose from Carthago’s accessory packs and optional extras to suit you.
Use the Carthago C1 Tourer T 145 RB-LE Lightweight Configurator (click here) to tailor your model.
When your configuration is complete, contact us to order your Carthago C1 Tourer T.
*Please Note: This vehicle listing contains library images; vehicle appearance may differ.*
