Core ModelBase Model Library Images

Hymer ML-T 570 CrossOver 4×4

Name: Hymer ML-T 570 CrossOver 4x4
SKU: FO102574
Price: 142170.00 GBP
Availability: BackOrder

£142,170.00

Enquire Now or call us on 02392 674820

Base model FROM £142,170.

See details below for specification included as standard, plus upgrade options. Price includes VAT and On The Road charges. These include delivery to the UK, vehicle registration and PDI. Possible import duties are not included and will be charged separately. Contact us for further details.

This luxurious Hymer is one to remember, with fixed rear twin single beds and a spacious lounge / dinette the motorhome gives plenty of room to entertain. Based on the all new Mercedes 4×4 chassis, standard with raised suspension and All-Terrain tyres, this van can simply take you anywhere!

Model Year:

2025

Chassis:

Mercedes Sprinter

Berth:

3 Berth

Gearbox:

Automatic 9-Speed

Length:

6.89m

GVW:

4100kgs

Compare Stock Number: FO102574

2025 Hymer ML-T 570 CrossOver 4×4

Discover the ML-T CrossOver 4X4 FL, Hymer’s CrossOver edition model makes no compromise. With its off-road suitability and self-sufficiency for up to 10 days, start your motorhome journey here.

Motorhome Technical Data:

Mercedes-Benz Sprinter 419 CDI
All Wheel Drive 4×4
190 HP / 140 kW
Euro VI-E
198cm standing height in living area
3,665mm wheelbase
Maximum laden mass: 4,100kg
Rear bed dimensions: 186x77cm / 190x77cm
Central bed dimensions: 175x79cm
Bathroom: 105x83cm
Wardrobe: 67x67x84cm
Kitchen: 97x50x93cm
154l fridge with 18l freezer
Standard heating: diesel warm air 6 kW
Gas bottle storage: 2x 6kg
Fresh water 120l
Waste water 100l
Sockets: 8x 230V / 3x 12V / 6x USB

Hymer ML-T 570 CrossOver Equipment Includes:

Base
- Permanent All Wheel Drive inc. 93l fuel tank
- Exterior cab colour: Tenorite Grey Metallic
- Exterior body colour: Crystal Silver Metallic
- Mercedes-Benz original ladder frame
- 9G-TRONIC automatic transmission inc. hold function
- 22l AdBlue tank
- Adaptive brake light
- Electrically adjustable and heated exterior mirrors
- Chrome grill
- Bumper, attachment parts and grill frame painted in vehicle colour
- Fog lights with cornering light
- Mud flaps, rear axle
- Reinforced front axle
- Trailer hitch pre-installation
- Windscreen made of laminated glass
- 16″ steel rim (black) with studded All Terrain tyres
- 16″ steel spare wheel with studded All Terrain tyre inc. mounting bracket on outside rear wall
- Shelf above windscreen
- Shelf for smartphones inc. wireless charging with charge level indicator
- Outside temperature display
- Electric cab windows and central locking for cab
- Electric parking brake
- Driver and passenger airbag
- Keyless start
- Dashboard charging pack (2 USB-C connections as well as additional 12V socket)
- Leather steering wheel
- Steering wheel, height and tilt adjustable
- Multifunctional steering wheel
- Open shelf cockpit passenger side
- Breakdown kit (air compressor with additional valve)
- Power steering
- Heated windscreen
- THERMOTRONIC fully automatic climate control
- ABS (Anti-lock Braking System) / ASR (Anti-Slip Control / EBV (Electric Brake Force Distribution) / ESP (Electronic Stability Program)
- DISTRONIC+ active distance assist inc. multifunctional steering wheel buttons
- Active brake assist
- Active lane keeping assist
- Attention assist
- Automatic headlight control
- Hill start assist
- Electric immobiliser
- High beam assist
- Headlight range adjustment
- Intelligent speed assistant
- Rain sensor
- Crosswind assist
- Headlight assistant
- Cruise control
- Traffic sign assist
Body
- Optimal PUAL sandwich insulation
- Exterior flap to load the L-shaped seating group from outside, LH side
- Electric entrance step
- Exclusive HYMER multifunctional rear lights in LED-hybrid technology
- Garage load up to 350kg (please note axle load)
- Large garage doors, LH and RH side
- GRP lightweight floor with XPS insulation
- Panoramic skylight above cab with integrative panelling, manually hinged
- HYMER panoramic skylight 80x50cm, double glazed with LED lighting, living room
- Skylight (clear glass) above rear beds with blackout blind and mosquito net 40x40cm
- Roof rack ladder without checker plate roof panel
- 44″ LED light bar above cab
- Engine / Underride protection
- Design graphics: CrossOver
- Comfort habitation door with window, blackout blind, integrated waste bin as well as 2-way lock
- Front wheel arch extensions
Outfitting
- Mercedes-Benz comfort seat in living are fabric, height and tilt adjustable, rotating, with 2 armrests and integral look
- Front seating group with 2 integrated 3-point belts
- Integrative cladding of the habitation door
- All overhead lockers with soft-close feature
- Comfort push locks with genuine leather loops on flaps and drawers
- Open shelf above cab
- Wall panel with multifunctional rail system in the entrance area and the seating group
- Mosquito net on habitation door
- Cab blinds
- Flyscreen and blackout blinds on all windows (in the body construction)
- Lashing rails in the garage
- Checker plate floor as well as felt trim in the rear garage
- External shower, located in the garage
- Tool set (folding spade, axe) in rear storage compartment
Living and Bedroom
- Multi-zone cold foam mattress inc. high-quality mattress pad (knitted fabric) for ventilation in the rear
- Multifunctional rail system on both sides in the sleeping area for versatile use
- Open compartment in the sleeping area inc. rubber strap
- Open shelf entrance element with stylish Coming Home lighting and additional storage space
- Partitioning curtain between bed and living room
- Complete LED interior lighting inc. night light
- LED gooseneck lights above cab inc. USB socket
- LED awning light
- Comfort L-shaped seating group with lounge cushions, longitudinal/transverse sliding table and two built-in 3-point seat belts
- Bed conversion for L-shaped seating group inc. lowerable table
- Sleeping comfort system with cup-slatted bed frame and Multizone cold foam mattress for rear bed
- Additional cushion between longitudinal single beds with ladder
- Fitted sheets made to measure for rear beds
- Four cushions
- Ambient lighting
- Complete LED interior lighting
Kitchen
- 3-burner gas cooker with ignition fuse, electric ignition, flame guard and glass cover
- 154l compressor fridge with two-way opening and removable freezer compartment (18l)
- Extra wide kitchen drawers inc. cutlery tray and Servo soft feature
- Kitchen wall panelling
- 8l waste bin in kitchen (can also be hung flexibly on drawer)
- Multifunctional rail
- Black matt water tap in high-class wall with tile optics
Bathroom
- Variable bathroom with swivel wall, roller door and black matt fittings
- Skylight (frosted glass) above shower with blackout blind, mosquito net as well as integrated clothes rail 40x40cm
- Bench toilet with level indicator and cassette on wheels
- Toothbrush cup inc. bracket
- Second toilet cassette inc. bracket located in external storage compartment
Installation and Technology
- 6 kW diesel warm air heating with 10l warm water boiler, atmospheric pressure sensor (altitude kit) and 1,800 W electric bar heater
- Gas bottle compartment with access via the external flap / door
- Warm air heating in the rear bedroom, adjustable separately
- LCD keypad for heating
- 230V external connection with earth leakage circuit breaker for 230V and 12V
- Charging booster for safe charging of the habitation battery while driving (up to 70 A)
- 7″ touch display for convenient control and monitoring of smart vehicle features
- HYMER Connect to control and monitor smart vehicle features via the HYMER Connect App.
- 120l fresh water tank, insulated and heated
- 100l waste water tank, insulated and heated
- Electric waste water drainage
- Additional sockets: 4x 230V / 1x 12V / 2x Twin-USB (USB A/C) inc. kitchen wall panelling
- Solar panel with solar charge controller (MPPT) and display, 2x 95 Watt
- Inverter 12V to 230V with network priority circuit
- HYMER Smart Battery System 2.0 (4x 80 Ah LFP) inc. additional charger
- Water filter for fresh water
Multimedia
- DAB radio
- Radio / TV pre-installation inc. 12V socket, two speakers in the cab, two speakers in the alcove, radio and DVB-T2 antenna
- 10.25″ MBUX Multimedia system with reversing camera, voice control, touchscreen inc. SatNav and smartphone integration
- Radio / TV pre-installation at sideboard inc. 12V and 230V socket, two speakers in the cab, low-profile bonnet as well as rear bedroom, radio and DVB-T2 antenna
Fabric and Furniture Finish
- Furniture finish: Native Bamboo
- Fabric combination: Indiana

Extra Items Available for the Hymer ML-T 570 CrossOver Motorhome

Order your Hymer ML-T 570 CrossOver to your own specification. Choose from Hymer’s accessory packs and optional extras to suit you.

Use the Hymer ML-T CrossOver Configurator (click here) to tailor your model.

When your configuration is complete, contact us to order your Hymer ML-T 570 CrossOver.

*Please Note: This vehicle listing contains library images; vehicle appearance may differ.*

Additional Information

Brand:

Hymer

Model:

ML-T CrossOver

Chassis:

Mercedes Sprinter

Body Type:

Low-Profile

LHD / RHD:

Right Hand Drive

Drive Axle:

All Wheel Drive 4X4

Condition:

New

Bathroom Type:

Premium Bathroom

Bed Layout:

Twin Single Rear Bed

Berth:

3 Berth

Engine Size:

2.0 Litre

Fuel Type:

Diesel

Garage Type:

Bike Garage

Gearbox:

Automatic 9-Speed

GVW:

4100kgs

Licence Requirement:

C1 Licence

Heating Type:

6kw Diesel Warm Air

Kitchen Type:

Central Kitchen

Length:

6.89m

Width:

2.22m

Height:

3.05m

Toilet Type:

Cassette

Seatbelts:

4 Belts

Paint Colour:

Tenorite Grey

Model Year:

2025
